Reprogramming a Raspberry Pi with Particle’s Asset OTA and a B504e

Then, create an assets folder at the root of the Particle project with an app.py file. In this file, you can put the test code shown below. This is the script to be sent to the Raspberry Pi.

import time

while True:
    print("Hello world! From the app.py file")
    time.sleep(2)

Next, in project.properties, uncomment the assetOtaDir line. This tells the Particle compiler where to find the bundled assets.

name=rpi-asset-ota-firmware
assetOtaDir=assets

In the main cpp file we can start writing out the logic. At the top of the file, add a function signature for the asset handler. Assign it to the onAssetOta callback.

void handleAssets(spark::Vector<ApplicationAsset> assets);
STARTUP(System.onAssetOta(handleAssets));

Below that, let’s fill out the asset handler function. This function finds the asset named app.py and begins to print its contents to the serial port using Serial.write.

Notice that we’re not using the logging subsystem here so that metadata doesn’t get sent along with the script contents. These calls to Serial will get swapped with Serial1 later on.

I’ve provided a unique start line (--- Begin … ---) and end line (--- End of file ---) so our future Raspberry Pi handler knows when to start saving the script data.

void handleAssets(spark::Vector<ApplicationAsset> assets)
{
  Log.info("Processing assets...");
  for (ApplicationAsset &asset : assets)
  {
    Log.info("Asset name: %s", asset.name().c_str());
    if (asset.name() == "app.py")
    {
      Log.info("Python file found, sending to serial");

      // Reset the asset to ensure we're at the beginning
      asset.reset();

      // Create a buffer for reading chunks
      const size_t BUFFER_SIZE = 128;
      char buffer[BUFFER_SIZE];

      // Print a header to serial
      Serial.printlnf("--- Begin %s (size: %d bytes) ---", asset.name().c_str(), asset.size());

      // Read and send data in chunks
      while (asset.available() > 0)
      {
        int bytesRead = asset.read(buffer, BUFFER_SIZE - 1);
        if (bytesRead > 0)
        {
          // Write directly to serial
          Serial.write((const uint8_t *)buffer, bytesRead);
        }
      }

      // Print a footer to serial
      Serial.println("\n--- End of file ---");

      // Add a small delay to ensure the data has been sent
      delay(100);
    }
  }
  System.assetsHandled(true);
}

Now, in the setup function we can configure the serial port and call handleAssets. The call to handleAssets only exists as a debugging step, feel free to remove this later.

void setup()
{
  Serial.begin(115200);
  waitFor(Serial.isConnected, 10000);
  delay(2000);

  // redo assets handling on next boot for demo purposes
  // This is just here to make it easier to see the early log messages on
  // the USB serial debug. You probably don't want this in production code.
  handleAssets(System.assetsAvailable());
}

Compile and flash the device to make sure everything is working as expected. Open the serial monitor and reset the board to confirm that the contents of app.py are being printed.

center

For future reference, when uploading a firmware release to the Particle console, you’ll want to use the .zip file that gets generated in target > 6.3.0 > b5som now that we have a bundled asset with our project. This is instead of the .bin file you’d normally upload. You can read more about this in the Particle documentation.

center

With this code running, your BSoM will log out the contents app.py on both a system reset and a successful Particle OTA. When you want to re-program your Raspberry Pi, just re-compile a new Particle firmware build and release it via the console.

You can find the full reference firmware in this GitHub repository.

The Raspberry Pi app should overwrite app.py and restart the subprocess any time a new script is received.

We’ll start by setting up a while loop that waits for a serial connection. If a connection is made, it will continuously read a new line from the serial port. If an exception is thrown, then the serial port is probably not available and we’ll try to reconnect.

If serial data is available and we’ve detected the start of the file, save its contents. If the end of the file is detected, try to execute the script.

Find the full Raspberry Pi application in the rpi-asset-ota-app GitHub repository.

def listen_serial():
    """Continuously listen for incoming Python scripts over serial and execute them."""
    print(f"Listening on {SERIAL_PORT} at {BAUD_RATE} baud...")

    retry_delay = 2  # Initial retry delay

    while True:
        try:
            with serial.Serial(SERIAL_PORT, BAUD_RATE, timeout=10) as ser:
                print("Serial connection established.")

                retry_delay = 2  # Reset delay on successful connection
                capturing = False
                script_data = []

                # Read lines continuously until an exception occurs
                while True:
                    line = ser.readline().decode("utf-8")

                    if "--- Begin app.py" in line:
                        capturing = True
                        script_data = []
                    elif "--- End of file ---" in line:
                        capturing = False
                        script_content = "\n".join(script_data)
                        print("Received script!")
                        save_script(script_content)
                        execute_script()
                    elif capturing:
                        script_data.append(line)

        except (serial.SerialException, FileNotFoundError) as e:
            print(f"Serial error: {e}")
            print(f"Retrying in {retry_delay} seconds...")
            time.sleep(retry_delay)
            retry_delay = min(retry_delay * 2, 60)  # Exponential backoff (max 60s)

if __name__ == "__main__":
    listen_serial()
